From Integrated Simplicity:

The question of how web-based (or 3rd party) consumers can work with pub/sub based services comes up a lot.

Many developers are used to implementing web services exposing methods on them like GetAllCustomers.

When moving to pub/sub and other more loosely coupled messaging patterns, developers look to implement the same pattern, opting for something like duplex GetCustomersRequest and GetCustomersResponse. The reasoning is simple and straightforward - it is difficult to push data over the web to consumers.

However, there are still ways to disconnect the preparation of the data from its usage thus gaining many of the advantages of pub/sub.

By employing REST principles and modelling our customer list as an explicit resource, web-based consumers would simply perform regular HTTP GET operations on the URI to get the list of customers.

The resource itself could be a simple XML file - it wouldn’t need to be dynamic at all.

You can get all the scalability benefits of pub/sub for web based consumers. All you need is a bit of REST

In the architectural principle of fully self contained messages, events “can - instantly and in future - be interpreted as the respective event without the need to rely on additional data stores that would need to be in time-sync with the event during message-processing.”

Also, “passing reference data in a message makes the message-consuming systems dependent on the knowledge and availability of actual persistent data that is stored “somewhere”. This data must separately be accessed for the sake of understanding the event that is represented by the message.”

The discussion of self-contained events can be compared to integration databases vs application databases.

Centralized Integration - Pros & Cons

If everything in a system can access a central datastore, it is enough for one party to publish an event containing only the ID of an entity that that party previously entered/updated. Upon receiving that event, a subscriber would go to the central datastore and get the fields its interested in for that ID. The advantage of this approach is that the minimal amount of data necessary crosses the network, as subscribers only retrieve the fields that interest them. Martin Fowler describes the disadvantages as:

“An integration database needs a schema that takes all its client applications into account. The resulting schema is either more general, more complex or both. The database usually is controlled by a separate group to the applications and database changes are more complex because they have to be negotiated between the database group and the various applications.”

This is far from being aligned with the principle of autonomy so important to SOA. In that respect, the architectural principle of self-contained messages points us away from those problems and towards more autonomous services.

However, once we have these autonomous business services in place, we may find that we don’t need 100% fully self-contained messages anymore.

A Real-World Example

Let’s say we have 3 business services, Sales, Fulfillment, and Billing.

Sales publishes an OrderAccepted event when it accepts an order. That event contains all the order information.

Both Fulfillment and Billing are subscribed to this event, and thus receive it.

Fulfillment does not ship products to the customer until the customer has been billed, so it just stores the order information internally, and is done.

Billing starts the process of billing the customer for their order, possibly joining several orders into a single bill. After completing this process, it publishes a CustomerBilled event containing all billing information, as well as the IDs of the orders in that bill. It does not put all the order information in that event, as it is not the authoritative owner of that data.

When Fulfillment receives the CustomerBilled event, it uses the IDs of the orders contained in the event to find the order information it previously stored internally. It does not need to call the Sales service for this information or contact some central Master Data Management system. It uses the data it has, and goes about fulfilling the orders and shipping the products to the customer, finally publishing its own OrderShipped event.

Notice, as well, that in the original OrderAccepted event there were the IDs of products the customer ordered. These product IDs originated from another service, Merchandising, responsible for the product catalog. The same thing can be said for the customer ID originating from another service - Customer Care.

The Issue of Time

One could argue that since subscribers use previously cached data when processing new events, that data might not be up to date. Also, we may have race conditions between our services. In the above example, if Billing was extremely fast and more highly available than Fulfillment. Billing could have received the OrderAccepted event, processed it, and published the CustomerBilled event before Fulfillment had received the OrderAccepted event. In short, the CustomerBilled and OrderAccepted messages could be out of order in Fulfillment’s queue.

What would Fulfillment do when trying to process the CustomerBilled message when it doesn’t have the order information?

Well, it knows that the world is parallel and non-sequential, so it does NOT return/log an error, but rather puts that message in the back of the queue to be processed again later (or maybe in some other temporary holding area). This enables the OrderAccepted message to be processed before the CustomerBilled message is retried. When the retry occurs, well, everything’s OK – it’s worked itself out over time.

In the case where we retry again and again and things don’t work themselves out (maybe the OrderAccepted event was lost), we move that message off to a different queue for something else to resolve the conflict (maybe a person, maybe software). If/when the conflict is resolved (got the Sales system / messaging system to replay the OrderAccepted event), the conflict resolver returns the CustomerBilled message to the queue, and now everything works just fine.

As all of this is occurring, the only thing that’s visible to external parties is that it happens to be taking longer than usual for the OrderShipped event to be published. In other words, time is the only difference.

Summary

The problem of non-self-contained events is mitigated first and foremost by business services in SOA, and the apparent issue of time-synchronization by business logic inside these services.

Don’t be afraid to put IDs in your messages and events.

Do be afraid of using those IDs to access datastores shared by multiple “services”.

Using IDs to correlated current events to data from previous events is not only OK, it’s to be expected.

The architectural principle of fully self-contained messages steers us away from the problems of Integration Databases and towards Application Databases, autonomous services, and a better SOA implementation. From there, following the principle of autonomy from a business perspective, will lead us to services not publishing data in their messages that is owned by other services, taking us the next step of our journey to SOA.

Related Content

[Podcast] Message Ordering - Is it cost effective?

Don’t EDA between existing systems

[Podcast] Handling dependencies between subscribers in SOA

One of the most common questions I get on the topic of pub/sub messaging is what happens if a notification is lost. Interestingly enough, there are some who almost entirely write-off this pattern because of this issue, preferring the control of request/response-exception. So, what should be done about lost messages? The short answer is durable messaging. The long answer is design.

Durable Messaging

In order to prevent a message from being lost when it is sent from a publisher to a subscriber, the message is written to disk on the publisher side, and then forwarded to the subscriber, where it is also written to disk. This store-and-forward mechanism enables our systems to gracefully recover from either side being temporarily unavailable.

In my MSDN article on this topic, I outlined some problems with this approach. These problems are exacerbated for publishers. Imagine a publisher with 40 subscribers, publishing 10 messages a second, each containing 1MB of XML. If 10 of the subscribers are unavailable, that’s 100MB of data being written to the publisher’s disk every second, 6GB every minute. That’s liable to bring down a publisher before an administrator brews a cup of coffee.

Publishers have no choice but to throw away messages after a certain period of time.

Publisher Contracts

The whole issue of contracts and schema is considered one of the better understand parts of SOA. Unfortunately, the operational aspects of service contracts is hardly ever taken into account.

On top of the schema of the messages a service publishers, additional information is needed in the contract:

1. How big will this message be?
2. How often will it be published?
3. How long will this message be stored if a subscriber is unavailable?

This first two pieces of information are important for subscribers to do load and capacity planning. The last one is the most important as it dictates the required availability and fault-tolerance characteristic of subscribers.

For Example

In the canonical retail scenario, when our sales service accepts an order, it publishes an order accepted event. Other services subscribed to this event include shipping, billing, and business intelligence.

While shipping and billing are highly available and able to keep up with the rate at which orders are accepted, the business intelligence service is not. BI has two main parts to it - a nightly batch that does the number crunching, and a UI for reporting off of the results of that number crunching. Some even do the reporting in a semi-offline fashion, emailing reports back to the user when they’re ready.

Furthermore, nobody’s going to invest in servers for making BI highly available.

And wasn’t the whole point of this publish/subscribe messaging to keep our services autonomous? That not all services have to have the same level uptime?

Houston, do we have a problem.?

Data Freshness

There is a glimmer of light in all this doom and gloom.

Not all services have the same data freshness requirements.

The business intelligence service above doesn’t need to know about orders the second they’re accepted. A daily roll-up would be fine, and an hourly roll-up bring us that much closer to “real time business intelligence”.

So, while BI is ready to accept the sales message schema, it would like a slightly different contract around it - less messages per unit of time, more data in each message.

From the operational perspective of the sales service, it would be cost effective to have less “online” subscribers. It could even take things a few steps further. Instead of using the regular messaging backbone for transmitting these hourly messages, it could use FTP. The data could even be zipped to take up even less space. Since the total data size is less than the corresponding online stream, is stored on cheaper, large storage, and the number of subscribers for this zipped, hourly update is fairly small, these messages can be kept around far longer.

If you’ve heard about consumer-driven contracts, this is it.

Note that we’re still talking about the same logical message schema.

Summary

It’s not that lost notifications aren’t a problem.

It’s that they feed the design process in such a way that the resulting service ecosystem is set up in such a way that notifications won’t get lost. I know that that sounds kind of recursive, but that’s how it works. Either subscribers take care of their SLA allowing them to process the online stream of events, or they should subscribe to a different pipe (which will have different SLA requirements, but maybe they can deal with those).

It make sense to have multiple pipes for the same logical schema.

It’s practically a necessity to make pub/sub a feasible solution.

Related Content

MSDN article on messaging and lost messages

Durable messaging dilemmas

Additional logic required for service autonomy

More in depth example on events and pub/sub between services

Consumer-Driven Contracts

There’s been some discussion on the SOA yahoo group around the connection between SOA, EDA, and CEP (complex event processing) since Jack’s original post on the topic. I’ve been waiting for the right opportunity to jump in and it seems to have come.

Dennis asked this:

There are different design choices in a SOA, even when you already have identified the services. I have a simple example that I would like to share:

Imagine a order-to-cash process. One part of that process is to register an order. Suppose we have two services, Order Service and Inventory Service. The task is to register the order and make a corresponding reservation of the stock level. I would be pleased to have the groups view on the following 3 design options (A, B, C):

A.
1. The “process/application” sends a message (sync or async) to “registerOrder” on the Order Service.
2. The “process/application” sends another message (sync or async) to “reserveStock” on the the Inventory Service.

B.
1. The “process/application” sends a message (sync or async) to “registerOrder” on the Order Service.
2. The Order Service sends a message (sync or async) to “reserveStock” on the the Inventory Service.

C.
1. The “process/application” sends a message (sync or async) to “registerOrder” on the Order Service.
2. The Order Service publishes an “orderReceived” event.
3. The Inventory Service subscribes to the “orderReceived” event .

On the whole “already identified the services” thing - naming a service doesn’t mean much. It’s all about allocating responsibility, and until that’s been done, those “services” don’t give us very much information.

Business Services

If we were to view this example in light of business services, and look at the business events that make up this process, maybe we’d get a different perspective.

Three business services: Sales, Inventory, and Shipping.

In Sales, many applications and people may operate, including the person and the application he used to submit the order. When the order is submitted and goes through all the internal validation stuff, Sales raises an OrderTentativelyAccepted event.

Inventory and Orders

Inventory, which is subscribed to this event, checks if it has everything in stock for the order. For every item in the order on stock, it allocates that stock to the order and publishes the InventoryAllocatedToOrder event for it. For items/quantities not in stock, it starts a long running process which watches for inventory changes.

When an InventoryChanged event occurs, it matches that against orders requiring allocation – if it finds one that requires stock, based on some logic to choose which order gets precedence, it publishes the InventoryAllocatedToOrder event.

Sales, which is subscribed to the InventoryAllocatedToOrder event, upon receiving all events pertaining to the order tentatively accepted, will publish an OrderAccepted event.

Orders and Shipping

When Inventory receives the OrderAccepted event, it generates the pick list to bring all the stock from the warehouses to the loading docks, finally publishing the PickListGenerated event containing target docks.

When Shipping receives the PickListGenerated event, it starts the yard management necessary to bring the needed kinds of trucks to the docks.

What else is possible

I could go on, talking about things like the maximum amount of time stock of various kinds can wait to be loaded on trucks, subscribing to earlier events to employ all kinds of optimization and prediction algorithms, having a Customer Care service notifying the customer about what’s going on with their order (probably different for different kinds of customers and preferred communication definitions). Obviously, we’d need a Billing service to handle the various kinds of billing procedures, whether or not the customer has credit, pays upon delivery, etc.

It turns out that many business domains map very well to this join of SOA and EDA.

What an ESB is for

When we have these kinds of business services primarily publishing events and subscribing to those of other services, you don’t need much else from your “enterprise service bus”. All sorts of transformation, routing, and orchestration capabilities don’t come into play at all.

In all truthfullness, those bits of functionality are really just a historical artifact of their broker heritage.

Don’t get me wrong, sometimes a broker is a nice thing to have - behind a service boundary in order to perform some complex integration between existing legacy applications.

Just keep that stuff in its place - not between services.

Complex Event Processing

We can look at how Sales transitions an order from being tentatively accepted to being accepted as requiring event correlation around InventoryAllocatedToOrder events. This isn’t exactly “complex” in its own right. If there were some kind of CEP engine that did this for us out of the box, it might be a possible technology choice for implementing this logic within our service.

As we add more concerns, like time, we may find new ways to make use of this engine. For instance, if the time to provide the order to the customer is approaching, we may choose to split the order into two - accepting one for which we have all the stock allocated, and leaving the second as tentatively accepted.

Summary

While it is difficult to move forward on service responsibility without discussing the events it raises and those it subscribe to, the whole issue of CEP can be postponed for a while.

Although there aren’t many who would say that EDA is necessary for driving down coupling in SOA, or that SOA won’t likely provide much value without EDA, or that SOA is necessary for providing the right boundaries for EDA, it’s been my experience that that is exactly the case.

CEP, while being a challenging engineering field, and managing the technical risks around it necessary for a project to succeed in some circumstances, and really shines when used under the SOA/EDA umbrella, it should not be taken by itself and used at the topmost architectural levels.

Related Content

SOA and Enterprise Processes

How client interaction fits with SOA

Time and SOA

Durable Messaging for Fault-Tolerant Services

And if you’re wondering about how to handle all that complexity inside services (different kinds of billing, periodic tests for electronics inventory, etc), you might like listening to this podcast about business components.

Of the tenets of Service Orientation, the tenet of Autonomy is one that many understand intuitively. Interestingly enough, many in that same intuitive category don’t see pub/sub as a necessity for that autonomy.

Watch that first step

Although sometimes described as the first step of an organization moving to SOA, web-service-izing everything results in synchronous, blocking, request/response interaction between services. The problem being that if one service were to become unavailable, all consumers of that service would not be able to perform any work. With the deep service “call stacks” this architectural style condones, the availability and performance of the entire organization will be dictated by the weakest link.

So, while I’d agree that many organizations do need to take this step, I’d caution against going into production at this step.

Pub/Sub Considered Helpful

When services interact with each other using publish/subscribe semantics we don’t have that technical problem of blocking. Subscribers cache the data published to them (either in memory or durably depending on their fault-tolerance requirements) thus enabling them to function and process requests even if the publisher is unavailable.

Consider the following scenario:

Let’s say we have an e-commerce site, a part of our Sales service responsible for selling products. Another service, let’s call it merchandising, is responsible for the catalog of products, and how much each product costs. Sales is subscribed to price update events published by Merchandising and saves (caches) those prices in its own database. When a customer orders some products on the site, Sales does not need to call Merchandising to get the price of the product and just uses the previously saved (cached) price. Thus, even if Merchandising is unavailable, Sales is able to accept orders. This is a big win as our merchandising application is not nearly as robust as our sales systems.

Yet, there are scenarios where data freshness requirements prevent this.

Too Much of a Good Thing?

Technically, the above story is accurate. There is nothing technically preventing Sales from accepting orders. Yet consider a scenario where Merchandising is down or unavailable for an extended period of time. While this may not be entirely likely for two servers in the same data center, consider physical kiosks which customers can use to buy products. Those kiosks may not receive updates for days. Should they accept orders?

That’s really a question to the business. If pricing data is stale for a time period greater than X, do not sell that item. The value of X may even be different for different kinds of products. Keep in mind that this issue only arose since we architected our services to be fully autonomous. In a synchronous systems architecture, this issue would not come up. As such, it is our responsibility as architects to go digging for these requirements as well as explaining to the business what the tradeoffs are.

In order to have more up to date data, we need to invest in more available hardware, networks, and infrastructure. This needs to be balanced against the predicted increase in revenue that more up to date (read higher) prices would give us.

You Can Get What You Pay For

Beyond the additional cost of writing that additional logic, and the perceived increased complexity, another difference to note between this architectural style and the synchronous/traditional one is that it puts control of spending back in the hands of business.

In a synchronous architecture, in order to achieve required performance and availability, all systems need to be performant requiring across the board investments in servers, networks, and storage. Without investing everywhere, the weakest link is liable to undo all other investments. In other words, your developers have made your investment choices for you. Scary, isn’t it.

A more prudent investment strategy would prefer spending on services that give the biggest bang for the buck, better known as return on investment. A pub/sub based architecture allows investing in data-freshness where it makes the most sense. For example, in sales of high profit products to strategic customers rather than inventory management of raw materials for products slated to be decommissioned.

That sounds a lot like IT-Business Alignment.

Maybe there’s something to this SOA thing after all…

Read more about:

7 Questions for Service Selection

7 Questions around data freshness

Event-Driven Architecture and Legacy Applications

Autonomous Services and Enterprise Entity Aggregation

Or listen to a podcast describing Business Components, the connection of pub/sub and SOA.

Another prominent SOA practitioner and blogger, Steve Jones, shows that, when you’re identifying your top level business services you shouldn’t be thinking about who’s going to consume them.

“We have three high level business services: Engagement, Management, [and] Production. […] they represent different operational ambitions. Engagement is all about quantity and then filtering. Management is about the quality and Production is about realising the benefits.”

Services are not about “are you being served?”

They’re not about re-use, and barely about use. Events are what it’s all about.

Each service has its own responsibility and does what it needs to do, business-wise, to achieve its goals. Whether it’s about increasing the number of leads, ensuring high-profile clients get good service, or maximizing equipment utilization, services take responsibility.

I know I harp on this a lot.

It’s because it’s that important.

One of the common questions I receive from people starting to use nServiceBus is how one-way messaging fits with showing the user a grid (or list) of data. Thinking about publish/subscribe usually just gets them even more confused. Trying to resolve all this with Service Oriented Architecture leaves them wondering - why bother?

In regular client-server development, the server is responsible for providing the client with all CRUD (create, read, update, and delete) capabilities. However, when users look at data they do not often require it to be up to date to the second (given that they often look at the same screen for several seconds to minutes at a time). As such, retrieving data from the same table as that being used for highly consistent transaction processing creates contention resulting in poor performance for all CRUD actions under higher load.

A Scalable Solution

One of the common answers to this question is for the server/service to publish a message when data changes (say, as the result of processing a message) and for clients to subscribe to these messages. When such a notification arrives at a client, the client would cache the data it needs. Then, when the user wants to see a grid of data, that data is already on the client. Of course, this solution doesn’t work so well for older client machines (like some point of service devices) or if there are millions of rows of data.

The thing is that this solution is one implementation of a more general pattern - command query separation (CQS).

Command Query Separation

Wikipedia describes CQS as a pattern where "… every method should either be a command that performs an action, or a query that returns data to the caller, but not both. More formally, methods should return a value only if they are referentially transparent and hence possess no side effects."

Martin Fowler is less strict about the use of CQS allowing for exceptions: "Popping a stack is a good example of a modifier that modifies state. Meyer correctly says that you can avoid having this method, but it is a useful idiom. So I prefer to follow this principle when I can, but I’m prepared to break it to get my pop."

So, how does separating commands from queries and SOA help at all in getting data to and from a UI? The answer is based on Pat Helland’s thinking as described in his article Data on the Inside vs. Data on the Outside.

Services Cross Boxes

The biggest lie around SOA is that services run.

Let that sink in a second.

Sure services have runnable components, but that’s not why they’re important.

I’ll skip the books of background and cut to the chase:

Services communicate with each other using publish/subscribe and one-way messaging. Services have components inside them. Inside a service, these components can communicate with each using synchronous RPC, or any other mechanism. Also, these components can reside on different machines.

This is broader than just scaling out a service. There can be service components running on the client as well as the server.

SOA & CQS

Combining these two concepts together, here’s what comes out:

In this solution there are two services that span both client and server - one in charge of commands (create, update, delete), the other in charge of queries (read). These services communicate only via messages - one cannot access the database of the other.

The command service publishes messages about changes to data, to which the query service subscribes. When the query service receives such notifications, it saves the data in its own data store which may well have a different schema (optimized for queries like a star schema).

The client component which is in charge of showing grids of data to the user behaves the same as it would in a regular layered/tiered architecture, using synchronous blocking request/response to get its data - SOA doesn’t change that.

Composite Applications

Although the client side components of both the command and query services are hosted in the same process, they are very much independent of each other. That being said, from an interoperability perspective (the one that most people attribute to SOA), all of the client-side components will likely be developed using the same technology - although there are already ways to host Java code in .NET and vice-versa.

Of course, once we talk about web UI’s things are a bit different - but still similar. While web-server-side there may be a level of independence, for browser side inter-component communications we’re still likely to target javascript. There, I’ve managed to say something technical supporting mashups and SOA without lying through my teeth.

On the Microsoft side with the recent release of the Composite Application Guidance & Library (pronounced "prism") I hope that more of these principles will be reaching the "smart client". The command pattern is especially critical in maintaining the separation while enabling communication to still occur so I’m glad that, as one of the Prism advisors, I was able to simplify that part (Glenn still has nightmares about that rooftop conversation).

Publish / Subscribe

In the "scalable solution" section up top I mentioned how publish/subscribe to the smart client is really just one implementation of CQS and SOA. So, how different is it really?

Well, there will probably be a different technology mapping. Instead of a star-schema OLAP product, we might simply store the published data in memory on the client. That is, if you designed your components to be technology agnostic.

In terms of the use of nServiceBus, the same component is going to be subscribing to the same type of message - all that’s different is that now every client will be having data pushed to them rather than this occurring server-side only.

You could have the same code deployed differently in the same system - stronger clients subscribing themselves, weaker ones using a remote server. Web servers would probably be considered stronger clients. This kind of flexible deployment has proven to be extremely valuable for my larger clients. The added benefit of enabling users to work (view data) even while offline (somewhere there’s no WIFI) is just icing on the cake.

A Word of Warning

Once the client starts receiving notifications, and handling those on a background thread (as it should) the code becomes susceptible to deadlocks and data races. Juval does a good job of outlining some of those with respect to the use of WCF. Prism doesn’t provide any assurances in this area either.

Summary

NServiceBus is not designed to be used for any and all types of communication in a given architecture. In the examples above, nServiceBus handles the publish/subscribe but leaves the synchronous RPC to existing solutions like WCF. Not only that, but synchronous RPC does have its place in architecture, just not across service boundaries. In all cases, data is served to users from a store different from that which transaction processing logic uses.

Command Query Separation is not only a good idea at the method/class level but has advantages at the SOA/System level as well - yet another good idea from 20 years ago that services build upon. Making use of CQS requires understanding your data and its uses - SOA builds on that by looking into data volatility and the freshness business requirements around it.

Finally, designing the components of your services in such a way that their dependency on technology is limited buys a lot of flexibility in terms of deployment and, consequently, significant performance and scalability gains.

Simple, it is. Easy, it is not.

“So, which services do I need?”

This innocuous question comes up a lot. Usually I get this question after a short problem domain description. One of these came up on the nServiceBus discussion groups. Ayende took it and ran with it turning it into a nice blog post, An exercise in designing SOA systems. I’ve been meaning to write something myself. Bill put up a response already in his Service Granularity Example. So, I’m late to the party, again, but here we go.

It’s almost impossible to know, right away, which services are appropriate.

So, I’m going to focus more on the process of getting there, rather than describing the solution itself.

The domain deals with a placement agency placing physicians in positions at hospitals.

1. So, what does it actually do?

In Ayende’s post, he describes several services, but I’d rather look at them as use cases: registering an open position, registering a candidate, verifying their credentials, etc. It’s worth going through this requirements process. It doesn’t necessarily translate immediately to services, but there’s value in it.

2. What does it do it to?

We should also be looking at the data model, an entity relationship diagram (ERD) , where we see that we may have placed a certain physician at a number of positions. It’s also important for us to know about under which circumstances a physician finished their employment at a previous position before, say, trying to place them at a position in the same hospital or chain of hospitals. Don’t go thinking that this what the database schema will look like, it’s all about understanding connections between various bits of data.

3. When does that happen?

The next step is to map the uses cases above to the entities in the ERD, which entity is used in which use case. It’s also important to differentiate between entities (or even more importantly, specific fields of entities) that are used in a read-only fashion within a given use case. For instance, when registering a new position, we’ll want to check that against other open positions in the same hospital so we don’t end up registering the same position twice. Also, we might want to suggest verified physicians whose credentials match the position’s requirements. Data we wouldn’t be interested in might be which other physicians we placed at that hospital.

4. What just happened?

Another valuable perspective on the problem domain is the business process view - what are the interesting business events in the system and how they unfold over time. For instance, physician registered, position opened, physician’s credentials verified, and physician placed in position (or position filled by physician) are events that describe a different business perspective than use cases.

5. How do I decide?

Once we know what events there are, we can start looking at what kind of decisions we might want to make when those events occur and what data we’d need to make those decisions. These decisions may be as simple as updating a database or sending an email to a user. They also may include more advanced logic like when the profitability of an agreement with a specific hospital chain changes, prefer placing physicians in positions in that chain over others.

6. How do I deal with all this information?

After we have all of this information, we can start looking for cohesive bunching across all of these axes using these rules:

• Data that is modified by a use case gets published as an event.
• Data that is required by a use case for read-only purposes, arrives as the result of subscribing to some event.

Look for rules that differentiate behaviour based on the properties of data. Look for a correlation to some business concept. For instance, physicians probably won’t be changing their specialization, and open positions often deal with a certain specialization. Therefore, specific data instances tied to two different specializations can be said to be loosely coupled.

7. Which property slices across the domain?

Even though the ERD may not have made it clear, and the use cases didn’t show any particular break-down, nor did the events call out this point, the key to finding the way a business domain decomposes into services lies in decoupling specific data instances.

Actually, at this point we can clump autonomous components (mere technical bits) that handle a single message, into more granular business components.

If you think about it, it makes a lot of sense. The kind of credential checking you’d do for physicians specializing in brain surgery would likely be different than for general practitioners. The kind of information you’d store would, therefore, also be different.

But, which services do I need?

Quite frankly, I don’t have enough information to know.

But if we had continued this conversation, going through issues like transactional consistency, availability requirements, and other non-functional issues we could have  gotten there.

If there’s one thing that I hope you got out of this, it’s that the questions are what’s important. The iterative process of looking at the problem domain from various perspectives, incorporating the new-found knowledge, and asking more questions is what leads us to a solution. But we don’t stop there. We keep looking for characteristics which split services apart into business components, and for consistency requirements that brings autonomous components together into services.

It’s not easy, but by focusing on these simple questions, you can get to a coherent service oriented architecture.

My long-time readers will no doubt remember Bill, he who has sent me so many great questions around SOA and gotten me to put some of my best podcast episodes out. Well, Bill’s now got a blog and he’s putting up a lot of great information on SOA (and that’s saying quite a bit, I barely agree with myself when it comes to SOA). In his post on Publish-Subscribe with Legacy Applications he discusses some ways to do the integration, but I want to talk here about WHO does the integration.

What’s on first?

Many times I see SOA projects integrate existing/legacy systems focusing only on getting those systems to talk to the ESB (bits flowing) using the right structures (canonical schema, oy). However, little attention is often given to where that integration code runs - in other words, which endpoint does the rest of the system talk to? Who’s in charge of the integration?

The answer is usually muddled - sometimes its the ESB itself (serving more as an EAI broker at that point), sometimes its some DLL that the calling service uses, but I VERY rarely hear anything about the actual process that’s hosting that code, the endpoint itself, or anything that will help us deal with Service-Level Agreements.

No. What’s on second.

If you can’t (or don’t want to) change the legacy application at all, I suggest setting up a new endpoint and an additional process which listens on that endpoint. That process is in charge of communicating with the legacy application and translating whatever is going on to the messaging semantics of the SOA environment. Not everything may be publish/subscribe - other systems may send command messages to the endpoint, resulting in API calls on the legacy application.

One of the things that the process can/should do, is to subscribe to events/messages from other services and feed the relevant information to the legacy application. At times this will be done on an as-needed basis from the legacy application’s perspective - it will call some API/web service that will need to communicate with the afore-mentioned process, and the process will return the data needed.

How is playing a different game

From the perspective of all the other services, the legacy application might as well not even be there - they communicate via the regular messaging semantics with everything.

What is important to understand is that developing that kind of process is not a trivial undertaking. In DDD terms, it can be called an Anti-Corruption Layer, as it prevents the legacy from influencing the structure of any other service. This procedure is one of the ways one can go about slowly getting data and functionality off of mainframes and into more versionable and change-friendly (and cheaper) environments.

I don’t give a darn!

Oh, that’s our esb.

There’s a fairly intense discussion going on these days amongst the SOA illuminati. In the hopes that people will see me standing beside them and conclude that I too know something, I’ve decided to chip in.

Jim brought the concept of cohesion to the regular SOA discussions around loose coupling in his post Anemic Service Model, which I think, all in all, is a very good idea.

Naïve Service Composition

Jim first calls out a common anti-pattern that seems to have become quite rampant - I’d call it naïve service composition if only the things being composed could even be called services. And I think the tone being set is correct - a service needs to meet a stronger set of criteria than just being able to be composed. Multiple services sharing the same logical data store (in that the same actual rows/data elements are managed by multiple services) probably means there’s an encapsulation problem here. I agree with Jim sentiment here:

“On the one hand we’re inclined, and indeed encouraged by the SOA brigade, to think of this architecture as a good fit for purpose because it is very loosely coupled. Since every component or service is decoupled from every other component or service it should be possible to arrange and re-arrange them in a Lego-style in a myriad of useful ways. Building out “business services” from some more fundamental set of services is how the books tell us to do it. In fact we could even do that quite easily with point-and-[click] BPM tools, ruling out such overheads as developers and change management along the way. Right?”

MVC? There are, like, 6 of them!

However, I disagree with some of the conclusions that Jim draws from that point. Jim states “build your services to implement business processes”, and that services are “just an instance of MVC”. I’m going to leave alone the MVC statement since there are like 6 documented kinds of MVC not including the Front Controller stuff that the web guys are now calling MVC. I’m going to focus on the business process advice. JJ also doesn’t seem to agree with this advice. As Savas has already taken issue with the tone of JJ’s response, I’ll keep my focus on the content.

Visual Cobol

First of all, in my previous conversations with Jim he had already denounced the procedural nature of composing higher-level business processes out of smaller services which implement small bits of common activities. Visual Cobol was how he described it. In JJ’s follow-up post, he called out the necessary aspect of autonomy that jives with Jim’s cohesion principle.

I’m a bit concerned about the way JJ tends to version what SOA means over time. It might make it impossible to have intelligent design discussions without tagging each sentence with “as SOA meant in 2006″. I acknowledge that the accepted meaning of SOA by various vendors has changed over the years. However, I’ve found that meanings rooted in decades of computer science tend to last and provide value that outlasts much of the industry-buzzword-bingo (SOA 2.0 anyone?).

Cohesion, Business Domains, and Business Processes

My view of the original cohesion principles Steve discusses in his 2005 article Old Measures for New Services takes a business spin to Functional Cohesion:

A service should be responsible for one business domain.

If we jump off from this point, we’ll see that certain business processes which occur entirely in one business domain are fully encapsulated, whereas those macro-processes which cross many domains (like Order to Cash) cross multiple services - they do not become a service since that would break the “one business domain” rule. Given that services are loosely coupled, avoiding temporal coupling leads to services raising events. Thus, macro-processes are really just a series of events of various services where each service does its own internal business processes.

Enterprise Processes >> Business Processes

I think that maybe some of the difficulty in discussing concrete SOA guidance has to do with granularity. I’ve started calling those macro-processes something different from business processes, and that may just bring me full circle to Jim’s guidance.

An Enterprise Process is any process which involves multiple business domains.

Under that definition, a service may be responsible for multiple business processes in the same business domain. But still, one business process is usually not a service by itself.

Business Components & Autonomous Components to the Rescue

Finally, by introducing the additional levels of decomposition of business components and autonomous components I’ve found that we can focus the discourse on one concern at a time. My presentation on the topic can be found here. The 30 second pitch is this:

Business domains are inherently partitionable - data and rules. A business component represents one partition. An example of this is the domain of Sales being partitioned by strategic and non-strategic customers. Although the data structure might be similar or the same, the actual rows/data elements are not shared. Rules around discounts are different.

Within a business component, different activities should not interfere with each other. An autonomous component represents one activity. In our example, reporting on orders from strategic customers should not interfere with accepting their orders. As such, those activities should have different messages coming in on different endpoints. Each endpoint could have different characteristics, like durability. Losing a request for a report when a server restarts isn’t a big deal, however not a good idea for orders.

For more information you could check out these episodes from my podcast:

Business and Autonomous Components in SOA

Using Autonomous Components for SLAs in SOA

Questions and comments are always welcome.
