A couple of weeks ago I gave a talk on Command/Query Responsibility Segregation in London.

The recording of the talk is online here.

There is one important thing that I didn’t have enough time to cover, but I want you to keep in mind as you’re watching this. It is that CQRS is applicable only *within* the context of a single service/BC – NOT across or between them.

Let me know what you think.

So it’s been about 6 months since my last NServiceBus post and since then about 1000 new people have subscribed to this blog so they might not know anything about it. For a bit of history, see the post (from almost exactly a year ago) describing the 1.9 release of NServiceBus here.

What’s New

The quickly approaching next release of NServiceBus will be version 2.0 and is a big step from 1.9. After 2 betas and 2 release candidates, this version has had a longer stabilization period than any of the versions so far (1.4-1.9). Many of my clients are already using it in production and are very pleased with it. I’ve heard similar reports from others in the community (now with over 500 members in the discussion group). There have been almost 10,000 downloads since the version 1.9 release and in every country I visit I meet people using NServiceBus in new and interesting applications.

With my appearance on Hanselminutes, many in the mainstream .NET industry have started taking a look at NServiceBus. That, and the fact that Microsoft’s Oslo technology has now taken a very data-driven turn (rather than its original service-oriented direction).

Interestingly enough, I’ve been hearing more and more reports about people using NServiceBus as a developer-friendly API on top of other technologies. This includes BizTalk and even Neuron. I never thought that people would take the pluggability of NServiceBus that far.

So, what is NServiceBus?

Well, it’s a service bus, y’know, like an ESB – just an open-source one.

All kidding aside, in a nutshell, it gives you an easy way to integrate transactional messaging into your applications.

One of the reasons why you might want to do that is so that you don’t lose messages containing valuable data when IIS recycles your AppDomain, every 15-20 minutes (as I wrote about in this MSDN magazine article).

There are many other nice things in there, like the ability to unit test your service layers and long-running processes but you can read more about that here…

Documentation

One of the biggest differences to NServiceBus in this release is documentation.

A lot of work has gone into the NServiceBus.com site to help developers hit the ground running with NServiceBus, including the more advanced aspects of transparent scale-out with the distributor and multi-site communications.

There is still work to be done in this area but feedback so far has been extremely positive (except for some grumblings from certain old-timers saying that if they could figure it out by themselves, well, you know the rest).

In Closing

If you’re building a distributed enterprise .NET system, take 5 minutes, download it, and see transactional publish/subscribe messaging working on your machine without any big heavy-weight middleware.

www.NServiceBus.com

After listening how the community has interpreted Command-Query Responsibility Segregation I think that the time has come for some clarification. Some have been tying it together to Event Sourcing. Most have been overlaying their previous layered architecture assumptions on it. Here I hope to identify CQRS itself, and describe in which places it can connect to other patterns.

Download as PDF – this is quite a long post.

Why CQRS

Before describing the details of CQRS we need to understand the two main driving forces behind it: collaboration and staleness.

Collaboration refers to circumstances under which multiple actors will be using/modifying the same set of data – whether or not the intention of the actors is actually to collaborate with each other. There are often rules which indicate which user can perform which kind of modification and modifications that may have been acceptable in one case may not be acceptable in others. We’ll give some examples shortly. Actors can be human like normal users, or automated like software.

Staleness refers to the fact that in a collaborative environment, once data has been shown to a user, that same data may have been changed by another actor – it is stale. Almost any system which makes use of a cache is serving stale data – often for performance reasons. What this means is that we cannot entirely trust our users decisions, as they could have been made based on out-of-date information.

Standard layered architectures don’t explicitly deal with either of these issues. While putting everything in the same database may be one step in the direction of handling collaboration, staleness is usually exacerbated in those architectures by the use of caches as a performance-improving afterthought.

A picture for reference

I’ve given some talks about CQRS using this diagram to explain it:

The boxes named AC are Autonomous Components. We’ll describe what makes them autonomous when discussing commands. But before we go into the complicated parts, let’s start with queries:

Queries

If the data we’re going to be showing users is stale anyway, is it really necessary to go to the master database and get it from there? Why transform those 3rd normal form structures to domain objects if we just want data – not any rule-preserving behaviors? Why transform those domain objects to DTOs to transfer them across a wire, and who said that wire has to be exactly there? Why transform those DTOs to view model objects?

In short, it looks like we’re doing a heck of a lot of unnecessary work based on the assumption that reusing code that has already been written will be easier than just solving the problem at hand. Let’s try a different approach:

How about we create an additional data store whose data can be a bit out of sync with the master database – I mean, the data we’re showing the user is stale anyway, so why not reflect in the data store itself. We’ll come up with an approach later to keep this data store more or less in sync.

Now, what would be the correct structure for this data store? How about just like the view model? One table for each view. Then our client could simply SELECT * FROM MyViewTable (or possibly pass in an ID in a where clause), and bind the result to the screen. That would be just as simple as can be. You could wrap that up with a thin facade if you feel the need, or with stored procedures, or using AutoMapper which can simply map from a data reader to your view model class. The thing is that the view model structures are already wire-friendly, so you don’t need to transform them to anything else.

You could even consider taking that data store and putting it in your web tier. It’s just as secure as an in-memory cache in your web tier. Give your web servers SELECT only permissions on those tables and you should be fine.

Query Data Storage

While you can use a regular database as your query data store it isn’t the only option. Consider that the query schema is in essence identical to your view model. You don’t have any relationships between your various view model classes, so you shouldn’t need any relationships between the tables in the query data store.

So do you actually need a relational database?

The answer is no, but for all practical purposes and due to organizational inertia, it is probably your best choice (for now).

Scaling Queries

Since your queries are now being performed off of a separate data store than your master database, and there is no assumption that the data that’s being served is 100% up to date, you can easily add more instances of these stores without worrying that they don’t contain the exact same data. The same mechanism that updates one instance can be used for many instances, as we’ll see later.

This gives you cheap horizontal scaling for your queries. Also, since your not doing nearly as much transformation, the latency per query goes down as well. Simple code is fast code.

Data modifications

Since our users are making decisions based on stale data, we need to be more discerning about which things we let through. Here’s a scenario explaining why:

Let’s say we have a customer service representative who is one the phone with a customer. This user is looking at the customer’s details on the screen and wants to make them a ‘preferred’ customer, as well as modifying their address, changing their title from Ms to Mrs, changing their last name, and indicating that they’re now married. What the user doesn’t know is that after opening the screen, an event arrived from the billing department indicating that this same customer doesn’t pay their bills – they’re delinquent. At this point, our user submits their changes.

Should we accept their changes?

Well, we should accept some of them, but not the change to ‘preferred’, since the customer is delinquent. But writing those kinds of checks is a pain – we need to do a diff on the data, infer what the changes mean, which ones are related to each other (name change, title change) and which are separate, identify which data to check against – not just compared to the data the user retrieved, but compared to the current state in the database, and then reject or accept.

Unfortunately for our users, we tend to reject the whole thing if any part of it is off. At that point, our users have to refresh their screen to get the up-to-date data, and retype in all the previous changes, hoping that this time we won’t yell at them because of an optimistic concurrency conflict.

As we get larger entities with more fields on them, we also get more actors working with those same entities, and the higher the likelihood that something will touch some attribute of them at any given time, increasing the number of concurrency conflicts.

If only there was some way for our users to provide us with the right level of granularity and intent when modifying data. That’s what commands are all about.

Commands

A core element of CQRS is rethinking the design of the user interface to enable us to capture our users’ intent such that making a customer preferred is a different unit of work for the user than indicating that the customer has moved or that they’ve gotten married. Using an Excel-like UI for data changes doesn’t capture intent, as we saw above.

We could even consider allowing our users to submit a new command even before they’ve received confirmation on the previous one. We could have a little widget on the side showing the user their pending commands, checking them off asynchronously as we receive confirmation from the server, or marking them with an X if they fail. The user could then double-click that failed task to find information about what happened.

Note that the client sends commands to the server – it doesn’t publish them. Publishing is reserved for events which state a fact – that something has happened, and that the publisher has no concern about what receivers of that event do with it.

Commands and Validation

In thinking through what could make a command fail, one topic that comes up is validation. Validation is different from business rules in that it states a context-independent fact about a command. Either a command is valid, or it isn’t. Business rules on the other hand are context dependent.

In the example we saw before, the data our customer service rep submitted was valid, it was only due to the billing event arriving earlier which required the command to be rejected. Had that billing event not arrived, the data would have been accepted.

Even though a command may be valid, there still may be reasons to reject it.

As such, validation can be performed on the client, checking that all fields required for that command are there, number and date ranges are OK, that kind of thing. The server would still validate all commands that arrive, not trusting clients to do the validation.

Rethinking UIs and commands in light of validation

The client can make of the query data store when validating commands. For example, before submitting a command that the customer has moved, we can check that the street name exists in the query data store.

At that point, we may rethink the UI and have an auto-completing text box for the street name, thus ensuring that the street name we’ll pass in the command will be valid. But why not take things a step further? Why not pass in the street ID instead of its name? Have the command represent the street not as a string, but as an ID (int, guid, whatever).

On the server side, the only reason that such a command would fail would be due to concurrency – that someone had deleted that street and that that hadn’t been reflected in the query store yet; a fairly exceptional set of circumstances.

Reasons valid commands fail and what to do about it

So we’ve got a well-behaved client that is sending valid commands, yet the server still decides to reject them. Often the circumstances for the rejection are related to other actors changing state relevant to the processing of that command.

In the CRM example above, it is only because the billing event arrived first. But “first” could be a millisecond before our command. What if our user pressed the button a millisecond earlier? Should that actually change the business outcome? Shouldn’t we expect our system to behave the same when observed from the outside?

So, if the billing event arrived second, shouldn’t that revert preferred customers to regular ones? Not only that, but shouldn’t the customer be notified of this, like by sending them an email? In which case, why not have this be the behavior for the case where the billing event arrives first? And if we’ve already got a notification model set up, do we really need to return an error to the customer service rep? I mean, it’s not like they can do anything about it other than notifying the customer.

So, if we’re not returning errors to the client (who is already sending us valid commands), maybe all we need to do on the client when sending a command is to tell the user “thank you, you will receive confirmation via email shortly”. We don’t even need the UI widget showing pending commands.

Commands and Autonomy

What we see is that in this model, commands don’t need to be processed immediately – they can be queued. How fast they get processed is a question of Service-Level Agreement (SLA) and not architecturally significant. This is one of the things that makes that node that processes commands autonomous from a runtime perspective – we don’t require an always-on connection to the client.

Also, we shouldn’t need to access the query store to process commands – any state that is needed should be managed by the autonomous component – that’s part of the meaning of autonomy.

Another part is the issue of failed message processing due to the database being down or hitting a deadlock. There is no reason that such errors should be returned to the client – we can just rollback and try again. When an administrator brings the database back up, all the message waiting in the queue will then be processed successfully and our users receive confirmation.

The system as a whole is quite a bit more robust to any error conditions.

Also, since we don’t have queries going through this database any more, the database itself is able to keep more rows/pages in memory which serve commands, improving performance. When both commands and queries were being served off of the same tables, the database server was always juggling rows between the two.

Autonomous Components

While in the picture above we see all commands going to the same AC, we could logically have each command processed by a different AC, each with it’s own queue. That would give us visibility into which queue was the longest, letting us see very easily which part of the system was the bottleneck. While this is interesting for developers, it is critical for system administrators.

Since commands wait in queues, we can now add more processing nodes behind those queues (using the distributor with NServiceBus) so that we’re only scaling the part of the system that’s slow. No need to waste servers on any other requests.

Service Layers

Our command processing objects in the various autonomous components actually make up our service layer. The reason you don’t see this layer explicitly represented in CQRS is that it isn’t really there, at least not as an identifiable logical collection of related objects – here’s why:

In the layered architecture (AKA 3-Tier) approach, there is no statement about dependencies between objects within a layer, or rather it is implied to be allowed. However, when taking a command-oriented view on the service layer, what we see are objects handling different types of commands. Each command is independent of the other, so why should we allow the objects which handle them to depend on each other?

Dependencies are things which should be avoided, unless there is good reason for them.

Keeping the command handling objects independent of each other will allow us to more easily version our system, one command at a time, not needing even to bring down the entire system, given that the new version is backwards compatible with the previous one.

Therefore, keep each command handler in its own VS project, or possibly even in its own solution, thus guiding developers away from introducing dependencies in the name of reuse (it’s a fallacy). If you do decide as a deployment concern, that you want to put them all in the same process feeding off of the same queue, you can ILMerge those assemblies and host them together, but understand that you will be undoing much of the benefits of your autonomous components.

Whither the domain model?

Although in the diagram above you can see the domain model beside the command-processing autonomous components, it’s actually an implementation detail. There is nothing that states that all commands must be processed by the same domain model. Arguably, you could have some commands be processed by transaction script, others using table module (AKA active record), as well as those using the domain model. Event-sourcing is another possible implementation.

Another thing to understand about the domain model is that it now isn’t used to serve queries. So the question is, why do you need to have so many relationships between entities in your domain model?

(You may want to take a second to let that sink in.)

Do we really need a collection of orders on the customer entity? In what command would we need to navigate that collection? In fact, what kind of command would need any one-to-many relationship? And if that’s the case for one-to-many, many-to-many would definitely be out as well. I mean, most commands only contain one or two IDs in them anyway.

Any aggregate operations that may have been calculated by looping over child entities could be pre-calculated and stored as properties on the parent entity. Following this process across all the entities in our domain would result in isolated entities needing nothing more than a couple of properties for the IDs of their related entities – “children” holding the parent ID, like in databases.

In this form, commands could be entirely processed by a single entity – viola, an aggregate root that is a consistency boundary.

Persistence for command processing

Given that the database used for command processing is not used for querying, and that most (if not all) commands contain the IDs of the rows they’re going to affect, do we really need to have a column for every single domain object property? What if we just serialized the domain entity and put it into a single column, and had another column containing the ID? This sounds quite similar to key-value storage that is available in the various cloud providers. In which case, would you really need an object-relational mapper to persist to this kind of storage?

You could also pull out an additional property per piece of data where you’d want the “database” to enforce uniqueness.

I’m not suggesting that you do this in all cases – rather just trying to get you to rethink some basic assumptions.

Let me reiterate

How you process the commands is an implementation detail of CQRS.

Keeping the query store in sync

After the command-processing autonomous component has decided to accept a command, modifying its persistent store as needed, it publishes an event notifying the world about it. This event often is the “past tense” of the command submitted:

MakeCustomerPerferredCommand -> CustomerHasBeenMadePerferredEvent

The publishing of the event is done transactionally together with the processing of the command and the changes to its database. That way, any kind of failure on commit will result in the event not being sent. This is something that should be handled by default by your message bus, and if you’re using MSMQ as your underlying transport, requires the use of transactional queues.

The autonomous component which processes those events and updates the query data store is fairly simple, translating from the event structure to the persistent view model structure. I suggest having an event handler per view model class (AKA per table).

Here’s the picture of all the pieces again:

Bounded Contexts

While CQRS touches on many pieces of software architecture, it is still not at the top of the food chain. CQRS if used is employed within a bounded context (DDD) or a business component (SOA) – a cohesive piece of the problem domain. The events published by one BC are subscribed to by other BCs, each updating their query and command data stores as needed.

UI’s from the CQRS found in each BC can be “mashed up” in a single application, providing users a single composite view on all parts of the problem domain. Composite UI frameworks are very useful for these cases.

Summary

CQRS is about coming up with an appropriate architecture for multi-user collaborative applications. It explicitly takes into account factors like data staleness and volatility and exploits those characteristics for creating simpler and more scalable constructs.

One cannot truly enjoy the benefits of CQRS without considering the user-interface, making it capture user intent explicitly. When taking into account client-side validation, command structures may be somewhat adjusted. Thinking through the order in which commands and events are processed can lead to notification patterns which make returning errors unnecessary.

While the result of applying CQRS to a given project is a more maintainable and performant code base, this simplicity and scalability require understanding the detailed business requirements and are not the result of any technical “best practice”. If anything, we can see a plethora of approaches to apparently similar problems being used together – data readers and domain models, one-way messaging and synchronous calls.

Although this blog post is over 3000 words (a record for this blog), I know that it doesn’t go into enough depth on the topic (it takes about 3 days out of the 5 of my Advanced Distributed Systems Design course to cover everything in enough depth). Still, I hope it has given you the understanding of why CQRS is the way it is and possibly opened your eyes to other ways of looking at the design of distributed systems.

Questions and comments are most welcome.

My latest article has been published in issue 21 of the Microsoft Architecture Journal:

EDA: SOA Through The Looking Glass

Please leave questions and comments here.

So, I’ve gotten back from a most enjoyable couple of days in Sweden where I gave two half-day tutorials, the first being the SOA and UI composition talk I gave at the European Virtual ALT.NET meeting (which you can find online here) and the other on DDD in enterprise apps (the first time I’ve done this talk).

I’ve gotten some questions about my DDD presentation there based on Aaron Jensen’s pictures:

Yes – I talk with my hands. All the time.

That slide is quite an important one – I talked about it for at least 2 hours.

Here it is again, this time in full:

You may notice that the nice clean layered abstraction that the industry has gotten so comfortable with doesn’t quite sit right when looking at it from this perspective. The reason for that is that this perspective takes into account physical distribution while layers don’t.

I’ll have some more posts on this topic as well as giving a session in TechEd Europe this November.

Oh – and please do feel free to already send your questions in.

Yesterday me and Scott virtually sat down to have a chat about NServiceBus and service buses in general. While we didn’t get in to many of the more advanced parts, you may find it an interesting introduction to the topic as well as saving yourself the costly mistake of implementing a broker instead of a bus (yes – they’re actually two different things).

Take a listen.

When working with clients, I run into more than a couple of people that have difficulty with event-driven architecture (EDA). Even more people have difficulty understanding what sagas really are, let alone why they need to use them. I’d go so far to say that many people don’t realize the importance of how sagas are persisted in making it all work (including the Workflow Foundation team).

The common e-commerce example

We accept orders, bill the customer, and then ship them the product.

Fairly straight-forward.

Since each part of that process can be quite complex, let’s have each step be handled by a service:

Sales, Billing, and Shipping. Each of these services will publish an event when it’s done its part. Sales will publish OrderAccepted containing all the order information – order Id, customer Id, products, quantities, etc. Billing will publish CustomerBilledForOrder containing the customer Id, order Id, etc. And Shipping will publish OrderShippedToCustomer with its data.

So far, so good. EDA and SOA seem to be providing us some value.

Where’s the saga?

Well, let’s consider the behavior of the Shipping service. It shouldn’t ship the order to the customer until it has received the CustomerBilledForOrder event as well as the OrderAccepted event. In other words, Shipping needs to hold on to the state that came in the first event until the second event comes in. And this is exactly what sagas are for.

Let’s take a look at the saga code that implements this. In order to simplify the sample a bit, I’ll be omitting the product quantities.

   1:      public class ShippingSaga : Saga<ShippingSagaData>,

   2:          ISagaStartedBy<OrderAccepted>,

   3:          ISagaStartedBy<CustomerBilledForOrder>

   4:      {

   5:          public void Handle(OrderAccepted message)

   6:          {

   7:              this.Data.ProductIdsInOrder = message.ProductIdsInOrder;

   8:          }

   9:

  10:          public void Handle(CustomerBilledForOrder message)

  11:          {

  12:               this.Bus.Send<ShipOrderToCustomer>(

  13:                  (m =>

  14:                  {

  15:                      m.CustomerId = message.CustomerId;

  16:                      m.OrderId = message.OrderId;

  17:                      m.ProductIdsInOrder = this.Data.ProductIdsInOrder;

  18:                  }

  19:                  ));

  20:

  21:              this.MarkAsComplete();

  22:          }

  23:

  24:          public override void Timeout(object state)

  25:          {

  26:

  27:          }

  28:      }

First of all, this looks fairly simple and straightforward, which is good.

It’s also wrong, which is not so good.

One problem we have here is that events may arrive out of order – first CustomerBilledForOrder, and only then OrderAccepted. What would happen in the above saga in that case? Well, we wouldn’t end up shipping the products to the customer, and customers tend not to like that (for some reason).

There’s also another problem here. See if you can spot it as I go through the explanation of ISagaStartedBy<T>.

Saga start up and correlation

The “ISagaStartedBy<T>” that is implemented for both messages indicates to the infrastructure (NServiceBus) that when a message of that type arrives, if an existing saga instance cannot be found, that a new instance should be started up. Makes sense, doesn’t it? For a given order, when the OrderAccepted event arrives first, Shipping doesn’t currently have any sagas handling it, so it starts up a new one. After that, when the CustomerBilledForOrder event arrives for that same order, the event should be handled by the saga instance that handled the first event – not by a new one.

I’ll repeat the important part: “the event should be handled by the saga instance that handled the first event”.

Since the only information we stored in the saga was the list of products, how would we be able to look up that saga instance when the next event came in containing an order Id, but no saga Id?

OK, so we need to store the order Id from the first event so that when the second event comes along we’ll be able to find the saga based on that order Id. Not too complicated, but something to keep in mind.

Let’s look at the updated code:

   1:      public class ShippingSaga : Saga<ShippingSagaData>,

   2:          ISagaStartedBy<OrderAccepted>,

   3:          ISagaStartedBy<CustomerBilledForOrder>

   4:      {

   5:          public void Handle(CustomerBilledForOrder message)

   6:          {

   7:              this.Data.CustomerHasBeenBilled = true;

   8:

   9:              this.Data.CustomerId = message.CustomerId;

  10:              this.Data.OrderId = message.OrderId;

  11:

  12:              this.CompleteIfPossible();

  13:          }

  14:

  15:          public void Handle(OrderAccepted message)

  16:          {

  17:              this.Data.ProductIdsInOrder = message.ProductIdsInOrder;

  18:

  19:              this.Data.CustomerId = message.CustomerId;

  20:              this.Data.OrderId = message.OrderId;

  21:

  22:              this.CompleteIfPossible();

  23:          }

  24:

  25:          private void CompleteIfPossible()

  26:          {

  27:              if (this.Data.ProductIdsInOrder != null && this.Data.CustomerHasBeenBilled)

  28:              {

  29:                  this.Bus.Send<ShipOrderToCustomer>(

  30:                     (m =>

  31:                     {

  32:                         m.CustomerId = this.Data.CustomerId;

  33:                         m.OrderId = this.Data.OrderId;

  34:                         m.ProductIdsInOrder = this.Data.ProductIdsInOrder;

  35:                     }

  36:                     ));

  37:                  this.MarkAsComplete();

  38:              }

  39:          }

  40:      }

And that brings us to…

Saga persistence

We already saw why Shipping needs to be able to look up its internal sagas using data from the events, but what that means is that simple blob-type persistence of those sagas is out. NServiceBus comes with an NHibernate-based saga persister for exactly this reason, though any persistence mechanism which allows you to query on something other than saga Id would work just as well.

Let’s take a quick look at the saga data that we’ll be storing and see how simple it is:

   1:      public class ShippingSagaData : ISagaEntity

   2:      {

   3:          public virtual Guid Id { get; set; }

   4:          public virtual string Originator { get; set; }

   5:          public virtual Guid OrderId { get; set; }

   6:          public virtual Guid CustomerId { get; set; }

   7:          public virtual List<Guid> ProductIdsInOrder { get; set; }

   8:          public virtual bool CustomerHasBeenBilled { get; set; }

   9:      }

You might have noticed the “Originator” property in there and wondered what it is for. First of all, the ISagaEntity interface requires the two properties Id and Originator. Originator is used to store the return address of the message that started the saga. Id is for what you think it’s for. In this saga, we don’t need to send any messages back to whoever started the saga, but in many others we do. In those cases, we’ll often be handling a message from some other endpoint when we want to possibly report some status back to the client that started the process. By storing that client’s address the first time, we can then “ReplyToOriginator” at any point in the process.

The manufacturing sample that comes with NServiceBus shows how this works.

Saga Lookup

Earlier, we saw the need to search for sagas based on order Id. The way to hook into the infrastructure and perform these lookups is by implementing “IFindSagas<T>.Using<M>” where T is the type of the saga data and M is the type of message. In our example, doing this using NHibernate would look like this:

   1:      public class ShippingSagaFinder :

   2:          IFindSagas<ShippingSagaData>.Using<OrderAccepted>,

   3:          IFindSagas<ShippingSagaData>.Using<CustomerBilledForOrder>

   4:      {

   5:          public ShippingSagaData FindBy(CustomerBilledForOrder message)

   6:          {

   7:              return FindBy(message.OrderId)

   8:          }

   9:

  10:          public ShippingSagaData FindBy(OrderAccepted message)

  11:          {

  12:              return FindBy(message.OrderId)

  13:          }

  14:

  15:          private ShippingSagaData FindBy(Guid orderId)

  16:          {

  17:              return sessionFactory.GetCurrentSession().CreateCriteria(typeof(ShippingSagaData))

  18:                  .Add(Expression.Eq("OrderId", orderId))

  19:                  .UniqueResult<ShippingSagaData>();

  20:          }

  21:

  22:          private ISessionFactory sessionFactory;

  23:

  24:          public virtual ISessionFactory SessionFactory

  25:          {

  26:              get { return sessionFactory; }

  27:              set { sessionFactory = value; }

  28:          }

  29:      }

For a performance boost, we’d probably index our saga data by order Id.

On concurrency

Another important note is that for this saga, if both messages were handled in parallel on different machines, the saga could get stuck. The persistence mechanism here needs to prevent this. When using NHibernate over a database with the appropriate isolation level (Repeatable Read – the default in NServiceBus), this “just works”. If/When implementing your own saga persistence mechanism, it is important to understand the kind of concurrency your business logic can live with.

Take a look at Ayende’s example for mobile phone billing to get a feeling for what that’s like.

Summary

In almost any event-driven architecture, you’ll have services correlating multiple events in order to make decisions. The saga pattern is a great fit there, and not at all difficult to implement. You do need to take into account that events may arrive out of order and implement the saga logic accordingly, but it’s really not that big a deal. Do take the time to think through what data will need to be stored in order for the saga to be fault-tolerant, as well as a persistence mechanism that will allow you to look up that data based on event data.

If you feel like giving this approach a try, but don’t have an environment handy for this, download NServiceBus and take a look at the samples. It’s really quick and easy to get set up.

My article on “optimizing a large-scale Software+Services application” has been published in the April edition of MSDN Magazine.

Here’s a short excerpt:

“We had to juggle occasional connectivity, data synchronization, and publish/subscribe all at the same time. We learned that we couldn’t solve all problems either client-side or server-side, but rather that an integrated approach was needed since any changes on one side needed corresponding changes on the other side.”

Continue reading…

There’s been some recent discussion as to the “cost” of messaging:

Greg Young asserts:

“I believe that this shows there to be a rather negligible cost associated with the use of such a model. There is however a small cost, this cost however I believe only exists when one looks at the system in isolation.”

Ayende adds his perspective:

“The cost of messaging, and a very real one, comes when you need to understand the system. In a system where message exchange is the form of communication, it can be significantly harder to understand what is going on.”

Of course, both these intelligent fellows are right. The reason for the apparent disparity in viewpoints has to do with which part of the following graph you look at. Ayende zooms in on the left side:

As systems get larger, though, the only way to understand them is by working at higher levels of abstraction. That’s where messaging really shines, as the incremental complexity remains the same by maintaining the same modularity as before:

In Ayende’s post, he follows the design I described a while back on using messaging for user management and login for a high-scale web scenario. In his comments, he agrees with the above stating:

“I certainly think that a similar solution using RPC would be much more complex and likely more brittle.”

I feel quite conservative in saying the most enterprise solutions fall on the right side of the intersection in the graph.

That being said, don’t underestimate the learning curve developers go through with messaging. While the mechanics are similar, the mindset is very different. Think about it like this:

You’ve driven a car for years in the US. It’s practically second nature. Then you fly to the UK, rent a car, and all of a sudden, your brain is in meltdown. (or vice versa for those going from the UK to the US)

Summary

If you are going down the messaging route, please be aware that there are shades of gray there as well. You don’t have to implement your user management and login the way I outlined in my post if you don’t require such high levels of scalability, but even lower levels of scalability can benefit from messaging.

Just as there isn’t a single correct design for non-messaging solutions, the same is true for those using messaging. Finding the right balance is tricky, and critical.

When the code is simple in every part of the system, and the asynchronous interactions are what provide for the necessary complexity the problem domain requires, that’s when you know you’ve got it just right.

From Integrated Simplicity:

The question of how web-based (or 3rd party) consumers can work with pub/sub based services comes up a lot.

Many developers are used to implementing web services exposing methods on them like GetAllCustomers.

When moving to pub/sub and other more loosely coupled messaging patterns, developers look to implement the same pattern, opting for something like duplex GetCustomersRequest and GetCustomersResponse. The reasoning is simple and straightforward – it is difficult to push data over the web to consumers.

However, there are still ways to disconnect the preparation of the data from its usage thus gaining many of the advantages of pub/sub.

By employing REST principles and modelling our customer list as an explicit resource, web-based consumers would simply perform regular HTTP GET operations on the URI to get the list of customers.

The resource itself could be a simple XML file – it wouldn’t need to be dynamic at all.

You can get all the scalability benefits of pub/sub for web based consumers. All you need is a bit of REST
